Component list
Component List
Resistors
All SMD 0603
R1 = 50Ohm
R2,R3 = 560Ohm
Capacitors
All ceramic
C1,C2 = 10µ 10V*, SMD 1206
C3..C6 = 100n 50V, SMD 0603
C7,C8 = 330n 25V*, SMD 1206
Semiconductors
D1–D4 = 1N4148, DO214AA
D5 = LED, red, SMD 0805
D6 = LED, blau, SMD 0805
IC1 = AD8479, SOIC-8
IC2 = 78L05F*, SOT89
IC3 = 79L05F*, SOT89
Miscellaneous
Coaxial cable*
Microphone cable*, 2-wire, shielded
Pin probes*
PCB
* see text
