Quiet-WIRE KSZ8061 Ethernet-IC from Microchip for demanding environments
January 22, 2016
on
on
The new KSZ8061 single-chip 10Base-T/100Base-TX Ethernet physical-layer transmitter/receiver from Microchip is classified for automotive and industrial applications and has been designed for data communications over cheap UTP cables. This is the first component of a new series that is based on the patented and programmable Quiet-WIRE® EMC technology, which offers reduced line emissions and superior receiver performance. The system reliability is also improved with Microchip's proven LinkMD+® advanced cable diagnostics in addition to the built-in signal-quality indicator for dynamic control of the margins of interconnection disturbances.
For energy-efficient applications Microchip's integrated EtherGREEN™ technology provides a unique, ultra-deep sleep mode with wake-up on signal detection, where the power consumption in standby mode is reduced down to the sub-microamp range.
.
With its fast start-up time and establishing a connection in less than 20 ms, the KSZ8061 is ideal for applications where start-up time is critical, such as rear-vision cameras for cars. The KSZ8061 series is available with a wide temperature range of -40 tot +105 °C for applications in demanding environments, such as industrial sensor networks, robotics, building automation and aviation.
This series of Ethernet PHY transmitters/receivers offers support for both MII as well as the RMII processor interfaces, for simple integration with a wide range of processors, MCUs and SoCs.
The evaluation board that permits the functionality and performance of the KSZ8061 to be tested is the KSZ8061MNX.
More information:
-IC: www.microchip.com/wwwproducts/Devices.aspx?product=KSZ8061
-Evaluation board: www.microchip.com/DevelopmentTools/ProductDetails.aspx?PartNO=ksz8061mnx-eval
