Watch Elektor Lab Talk: Summer Circuits 22, a Retro Siren Circuit, and More
August 09, 2022
on
on
Are you curious about Elektor's extra-thick Summer Circuits 2022 edition? Join us for another live edition of Elektor Lab Talk on August 18, 2022, at 18:00 CEST on YouTube. Mathias Claussen (Senior Engineer, Elektor) and Jens Nickel (Editor in Chief, Elektor) will talk about Elektor Summer Circuits 2022 and many of the exciting projects inside the magazine. They will also give away five free Elektor US-Style Sirens! Don’t miss the livestream.
The Elektor US-Style Siren is a classic from the extremely popular sound-generator class copiously served by Elektor. The circuit — is based on inexpensive, old-school, through-hole parts — will make a great addition to your desk or workspace.
The circuit generates three different “US-style” siren sounds: police, ambulance, and fire brigade. You can select the desired sound using switch S1. Push button S2 was added for on/off control. The circuit consists of three parts, a modulator (T1 & T2), a sound generator (T3 & T4), and an amplifier (T5).
Mathias and Jens will give away five of them during the Elektor Lab Talk show! Be sure to tune in.
Elektor Summer Circuits 2022
The Summer Circuits edition features circuits, projects, in-depth articles, an interview and more. In typical Elektor fashion, we’ve planned a little something for everyone, from professional engineers to makers. It's a collector’s item!The Elektor US-Style Siren is a classic from the extremely popular sound-generator class copiously served by Elektor. The circuit — is based on inexpensive, old-school, through-hole parts — will make a great addition to your desk or workspace.
Mathias and Jens will give away five of them during the Elektor Lab Talk show! Be sure to tune in.
More Elektor Lab Talk
Visit the Lab Talk webpage to access past shows and to learn which what's in the pipeline.Read full article
