A preamplifier-equaliser for magnetic pickup cartridges has to meet quite exacting requirements. Values for gain, noise level and maximum input voltage which will guarantee trouble-free operation under all conditions are not so easy to achieve. The well-known two-transistor configuration, operating from a 12 ... 18 V supply, invariably falls short on gain and overdrive-margin - unless it is designed for a low nominal output voltage (about 30 mV). An alternative approach is to make use of a good integrated amplifier. The design about to be described, which meets all the requirements, employs a SN 76131. An almost identical I.C. is the µA 739.
