GateMate FPGA Evaluation Board

The GateMate^TM FPGA family of Cologne Chip AG addresses all application requirements of small to medium size FPGAs. Logic capacity, power consumption, package size and PCB compatibility are best in class. GateMate^TM FPGAs combine these features with the lowest cost in industry making the devices well suited from University projects to high volume applications.
  The GateMate^TM Evaluation Board is a feature-rich, ready-to-use development platform for the Cologne Chip CCGM1A1 FPGA. It serves as a reference design and for a direct entry into application development. User applications can be tailored to each of the six available I/O banks.  Attaching additional hardware is a breeze thanks to the Pmod connectors: They allow access to a variety of peripheral boards, including motor controllers, sensors, displays and more.

In order to offer the widest possible range of applications for your evaluation, the Evaluation Board offers all the minimum require peripheral components such as memory, clock and access to a large number of interfaces and allows control over the core an IO voltages.

Features



• GateMate A1 FPGA
  • 20,480 programmable elements
  • 0.9-1.1V core voltage, 1.2-2.5V I/O voltage
  • 32 dual-port block RAM cells, total: 1,280 Kbit
  • 4 configurable PLLs
  • all GPIO configurable as single-ended or LVDS differential pairs
  • 324 balls 0.8 mm FPGA package, 15x15 mm

• Interfaces
  • USB-JTAG + USB-SPI configuration interface
  • 2 Pmod-compatible ports
  • 6 GPIO banks

•  Memory
  • 64 Mbit Quad-I/O SPI flash
  • 64 Mbit HyperRAM

• Dimensions
  • 100x160 mm (Eurocard standard)
